My first deploys for a new Kubernetes cluster
Published on , 1981 words, 8 minutes to read
This is documentation for myself, but you may enjoy it too
I'm setting up some cloud Kubernetes clusters for a bit coming up on the blog. As a result, I need some documentation on what a "standard" cluster looks like. This is that documentation.
Every Kubernetes term is WrittenInGoPublicValueCase. If you aren't sure what one of those terms means, google "site:kubernetes.io KubernetesTerm".
I'm assuming that the cluster is named mechonis.
For the "core" of a cluster, I need these services set up:
- Secret syncing with the 1Password operator
- Certificate management with cert-manager
- DNS management with external-dns
- HTTP ingress with ingress-nginx
- High-latency high-volume storage with csi-s3 pointed to Tigris (technically optional, but including it for consistency)
- The metrics-server so k9s can see how much free CPU and RAM the cluster has
These all complete different aspects of the three core features of any cloud deployment: compute, network, and storage. Most of my data will be hosted in the default StorageClass implementation provided by the platform (or in the case of baremetal clusters, something like Longhorn), so the csi-s3 StorageClass is more of a "I need lots of data but am cheap" than anything.
Most of this will be managed with helmfile, but 1Password can't be.
1Password
The most important thing at the core of my k8s setups is the 1Password operator. This syncs 1password secrets to my Kubernetes clusters, so I don't need to define them in Secrets manually or risk putting the secret values into my OSS repos. This is done separately as I'm not able to use helmfile
After you have the op command set up, create a new server with access to the Kubernetes vault:
op connect server create mechonis --vaults Kubernetes
Then install the 1password connect Helm release with operator.create set to true:
helm repo add \
1password https://1password.github.io/connect-helm-charts/
helm install \
connect \
1password/connect \
--set-file connect.credentials=1password-credentials.json \
--set operator.create=true \
--set operator.token.value=$(op connect token create --server mechonis --vault Kubernetes)
Now you can deploy OnePasswordItem resources as normal:
apiVersion: onepassword.com/v1
kind: OnePasswordItem
metadata:
name: falin
spec:
itemPath: vaults/Kubernetes/items/Falin
cert-manager, ingress-nginx, metrics-server, and csi-s3
In the cluster folder, create a file called helmfile.yaml. Copy these contents:
helmfile.yaml
repositories:
- name: jetstack
url: https://charts.jetstack.io
- name: csi-s3
url: cr.yandex/yc-marketplace/yandex-cloud/csi-s3
oci: true
- name: ingress-nginx
url: https://kubernetes.github.io/ingress-nginx
- name: metrics-server
url: https://kubernetes-sigs.github.io/metrics-server/
releases:
- name: cert-manager
kubeContext: mechonis
chart: jetstack/cert-manager
createNamespace: true
namespace: cert-manager
version: v1.16.1
set:
- name: installCRDs
value: "true"
- name: prometheus.enabled
value: "false"
- name: csi-s3
kubeContext: mechonis
chart: csi-s3/csi-s3
namespace: kube-system
set:
- name: "storageClass.name"
value: "tigris"
- name: "secret.accessKey"
value: ""
- name: "secret.secretKey"
value: ""
- name: "secret.endpoint"
value: "https://fly.storage.tigris.dev"
- name: "secret.region"
value: "auto"
- name: ingress-nginx
chart: ingress-nginx/ingress-nginx
kubeContext: mechonis
namespace: ingress-nginx
createNamespace: true
- name: metrics-server
kubeContext: mechonis
chart: metrics-server/metrics-server
namespace: kube-system
Create a new admin access token in the Tigris console and copy its access key ID and secret access key into secret.accessKey and secret.secretKey respectively.
Run helmfile apply:
$ helmfile apply
This will take a second to think, and then everything should be set up. The LoadBalancer Service may take a minute or ten to get a public IP depending on which cloud you are setting things up on, but once it's done you can proceed to setting up DNS.
external-dns
The next kinda annoying part is getting external-dns set up. It's something that looks like it should be packageable with something like Helm, but realistically it's such a generic tool that you're really better off making your own manifests and deploying it by hand. In my setup, I use these features of external-dns:
- The AWS Route 53 DNS backend
- The AWS DynamoDB registry to remember what records should be set in Route 53
You will need two DynamoDB tables:
external-dns-mechonis-crd: for records created with DNSEndpoint resourcesexternal-dns-mechonis-ingress: for records created with Ingress resources
Create a terraform configuration for setting up these DynamoDB configuration values:
main.tf
terraform {
backend "s3" {
bucket = "within-tf-state"
key = "k8s/mechonis/external-dns"
region = "us-east-1"
}
}
resource "aws_dynamodb_table" "external_dns_crd" {
name = "external-dns-crd-mechonis"
billing_mode = "PROVISIONED"
read_capacity = 1
write_capacity = 1
table_class = "STANDARD"
attribute {
name = "k"
type = "S"
}
hash_key = "k"
}
resource "aws_dynamodb_table" "external_dns_ingress" {
name = "external-dns-ingress-mechonis"
billing_mode = "PROVISIONED"
read_capacity = 1
write_capacity = 1
table_class = "STANDARD"
attribute {
name = "k"
type = "S"
}
hash_key = "k"
}
Create the tables with terraform apply:
terraform init
terraform apply --auto-approve # yolo!
While that cooks, head over to ~/Code/Xe/x/kube/rhadamanthus/core/external-dns and copy the contents to ~/Code/Xe/x/kube/mechonis/core/external-dns. Then open deployment-crd.yaml and replace the DynamoDB table in the crd container's args:
args:
- --source=crd
- --crd-source-apiversion=externaldns.k8s.io/v1alpha1
- --crd-source-kind=DNSEndpoint
- --provider=aws
- --registry=dynamodb
- --dynamodb-region=ca-central-1
- - --dynamodb-table=external-dns-crd-rhadamanthus
+ - --dynamodb-table=external-dns-crd-mechonis
And in deployment-ingress.yaml:
args:
- --source=ingress
- - --default-targets=rhadamanthus.xeserv.us
+ - --default-targets=mechonis.xeserv.us
- --provider=aws
- --registry=dynamodb
- --dynamodb-region=ca-central-1
- - --dynamodb-table=external-dns-ingress-rhadamanthus
+ - --dynamodb-table=external-dns-ingress-mechonis
Apply these configs with kubectl apply:
kubectl apply -k .
Then write a DNSEndpoint pointing to the created LoadBalancer. You may have to look up the IP addresses in the admin console of the cloud platform in question.
load-balancer-dns.yaml
apiVersion: externaldns.k8s.io/v1alpha1
kind: DNSEndpoint
metadata:
name: load-balancer-dns
spec:
endpoints:
- dnsName: mechonis.xeserv.us
recordTTL: 3600
recordType: A
targets:
- whatever.ipv4.goes.here
- dnsName: mechonis.xeserv.us
recordTTL: 3600
recordType: AAAA
targets:
- 2000:something:goes:here:lol
Apply it with kubectl apply:
kubectl apply -f load-balancer-dns.yaml
This will point mechonis.xeserv.us to the LoadBalancer, which will point to ingress-nginx based on Ingress configurations, which will route to your Services and Deployments, using Certs from cert-manager.
cert-manager ACME issuers
Copy the contents of ~/Code/Xe/x/kube/rhadamanthus/core/cert-manager to ~/Code/Xe/x/kube/mechonis/core/cert-manager. Apply them as-is, no changes are needed:
kubectl apply -k .
This will create letsencrypt-prod and letsencrypt-staging ClusterIssuers, which will allow the creation of Let's Encrypt certificates in their production and staging environments. 9 times out of 10, you won't need the staging environment, but when you are doing high-churn things involving debugging the certificate issuing setup, the staging environment is very useful because it has a much higher rate limit than the production environment does.
Deploying a "hello, world" workload
Nearly every term for "unit of thing to do" is taken by different aspects of Kubernetes and its ecosystem. The only one that isn't taken is "workload". A workload is a unit of work deployed somewhere, in practice this boils down to a Deployment, its Service, any PersistentVolumeClaims, Ingresses, or other resources that it needs in order to run.
Now you can put everything into test by making a simple "hello, world" workload. This will include:
- A ConfigMap to store HTML to show to the user
- A Deployment to run nginx pointed at the contents of the ConfigMap
- A Service to give an internal DNS name for that Deployment's Pods
- An Ingress to route traffic to that Service from the public Internet
Make a folder called hello-world and put these files in it:
configmap.yaml
apiVersion: v1
kind: ConfigMap
metadata:
name: hello-world
data:
index.html: |
<html>
<head>
<title>Hello World!</title>
</head>
<body>Hello World!</body>
</html>
deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
name: hello-world
spec:
selector:
matchLabels:
app: hello-world
replicas: 1
template:
metadata:
labels:
app: hello-world
spec:
containers:
- name: web
image: nginx
ports:
- containerPort: 80
volumeMounts:
- name: html
mountPath: /usr/share/nginx/html
volumes:
- name: html
configMap:
name: hello-world
service.yaml
apiVersion: v1
kind: Service
metadata:
name: hello-world
spec:
ports:
- port: 80
protocol: TCP
selector:
app: hello-world
ingress.yaml
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
name: hello-world
annotations:
cert-manager.io/cluster-issuer: "letsencrypt-prod"
nginx.ingress.kubernetes.io/ssl-redirect: "true"
spec:
ingressClassName: nginx
tls:
- hosts:
- hello.mechonis.xeserv.us
secretName: hello-mechonis-xeserv-us-tls
rules:
- host: hello.mechonis.xeserv.us
http:
paths:
- path: /
pathType: Prefix
backend:
service:
name: hello-world
port:
number: 80
kustomization.yaml
resources:
- configmap.yaml
- deployment.yaml
- service.yaml
- ingress.yaml
Then apply it with kubectl apply:
kubectl apply -k .
It will take a minute for it to work, but here are the things that will be done in order so you can validate them:
- The Ingress object has the
cert-manager.io/cluster-issuer: "letsencrypt-prod"annotation, which triggers cert-manager to create a Cert for the Ingress - The Cert notices that there's no data in the Secret
hello-mechonis-xeserv-us-tlsin the default Namespace, so it creates an Order for a new certificate from theletsencrypt-prodClusterIssuer (set up in the cert-manager apply step earlier) - The Order creates a new Challenge for that certificate, setting a DNS record in Route 53 and then waiting until it can validate that the Challenge matches what it expects
- cert-manager asks Let's Encrypt to check the Challenge
- The Order succeeds and the certificate data is written to the Secret
hello-mechonis-xeserv-us-tlsin the default Namespace - ingress-nginx is informed that the Secret has been updated and rehashes its configuration accordingly
- HTTPS routing is set up for the
hello-worldservice so every request tohello.mechonis.xeserv.uspoints to the Pods managed by thehello-worldDeployment - external-dns checks for the presence of newly created Ingress objects it doesn't know about, and creates Route 53 entries for them
This results in the hello-world workload going from nothing to fully working in about 5 minutes tops. Usually this can be less depending on how lucky you get with the response time of the Route 53 API. If it doesn't work, run through resources in this order in k9s:
- The
external-dns-ingressPod logs - The
cert-managerPod logs - Look for the Cert, is it marked as Ready?
- Look for that Cert's Order, does it show any errors in its list of events?
- Look for that Order's Challenge, does it show any errors in its list of events?
By the way: k9s is fantastic. You should have it installed if you deal with Kubernetes. It should be baked into kubectl. It's a near perfect tool.
Conclusion
From here you can deploy anything else you want, as long as the workload configuration kinda looks like the hello-world configuration. Namely, you MUST have the following things set:
- Ingress objects MUST have the
cert-manager.io/cluster-issuer: "letsencrypt-prod"annotation, if they don't, then no TLS certificate will be minted - Workloads MUST have the
nginx.ingress.kubernetes.io/ssl-redirect: "true"to ensure that all plain HTTP traffic is upgraded to HTTPS - Sensitive data MUST be managed in 1Password via OnePasswordItem objects
If you work at a cloud provider that offers managed Kubernetes, I'm looking for a new place to put my website, sponsorship would be greatly appreciated!
Happy kubeing all!
