Site Update: Version 3.0

Read time in minutes: 20

hero image aoi-onsen
Image generated by Waifu Diffusion v1.3 (float16) -- 1girl, fox ears, dark blue hair, blue eyes, kimono, festival, landscape, makoto shinrai, arknights, fireworks, pagodas, onsen, long hair, princess, -hands, -amputee

Hey all! Welcome to Xesite 3.0! Over the last few days I've taken a huge chunk out of my backlog and I have redone a lot of this website. My hope is that this will make it faster, more reliable and ultimately make things a lot easier for everyone. There's a lot of improvements here so I'm just going to start going over them one by one.

Project name changed

This website has historically been named site. It's had a lot of work put into it over the years and I've never really referred to it by anything but "the website" or "my blog". However I've noticed a change in my notes and I think I should make this official. The project behind this website is now officially called xesite.

Mara is hmm
<Mara> What about all of the custom HTML tags? Aren't they all called xeblog-$NAME? Are you going to change those?

Cadey is coffee
<Cadey> The custom HTML tags are an implementation detail, not something that is exposed to end users. Plus, those are now in my muscle memory so I can't really change those if I wanted to.

Blogpost series have metadata

When I implemented series support in the blog, it was kind of a hack. Series are intended to function kind of like tags, but more for tagging things that progress in a logical series. As an example, take a look at the page for my site-to-site WireGuard VPN series. It shows a little description for the series and in the future I will likely add other metadata like a series image.

This is powered by my new SeriesDescription Dhall record type.

Mara is hacker
<Mara> For context, Dhall is a Haskell-like non-Turing-complete configuration language that you can think of like JSON or YAML but with functions, imports, and static types.

I've never really covered how Dhall works on this blog before, so I'll take a look at this and the seriesDescriptions.dhall file to show off how damn cool Dhall is.

One of the most unique features of Dhall as a configuration language is its record completion operator ::. This allows you to specify a record (read: object)'s type and also a set of default values for that record. Let's take a look at the SeriesDescription record type:

-- dhall/types/SeriesDescription.dhall
{ Type = { name : Text, details : Text }
, default = { name = "", details = "" }
}

If I wanted to use this from inside my Dhall configuration, I would need to:

  • Import the type
  • Create a value with the :: operator

The description for the site-to-site-wireguard series could look something like this:

-- dhall/series/site-to-site-wireguard.dhall
let xesite = ../types/package.dhall

let SeriesDescription = xesite.SeriesDescription

in SeriesDescription::{
   , name = "site-to-site-wireguard"
   , details = "Instructions on setting up your own VPN with WireGuard."
   }

You declare your imports with URLs or filesystem paths and other aliases using let, and then you declare what to do with those variables after in. If you've never used Haskell or Lisp before, you can imagine let creating a block of scope just like an extra layer of curly braces in JavaScript or other C-like languages:

{
  let foo = "bar";
  console.log(foo);
}

// foo isn't usable from here

As you can imagine, this gets way more elaborate when you get more detail into the mix. However, it's all really easy to understand. It's just different than you might be expecting at first glance.

If you've never really used Dhall before, I really suggest taking a look at it. It's what I use for the configuration of all of my tools when I'm allowed to make those decisions. It's also got the ability to read from environment variables, which can make it easier to safely turn a bunch of raw strings from the environment into a more sensible datatype.

New type for the Signal Boost data file

One of my most successful parts of this site is the signal boost page. It was the first place I used Dhall on this website, and is one of the most contributed to things I've ever had in one of my own projects.

When I designed the schema forever ago, I apparently decided that people should only have one of a few types of links. I thought a Twitter and GitHub link should be sufficient. The Dhall type used to look something like this:

{ Type =
    { name : Text
    , tags : List Text
    , gitLink : Optional Text
    , twitter : Optional Text
    , linkedin : Optional Text
    , fediverse : Optional Text
    , coverLetter : Optional Text
    , website : Optional Text
    }
, default =
  { name = ""
  , tags = [] : List Text
  , gitLink = None Text
  , twitter = None Text
  , linkedin = None Text
  , fediverse = None Text
  , coverLetter = None Text
  , website = None Text
  }
}

I was wrong. That is not generic enough. Recently I got this pull request that made me really rethink how I'm doing this. I don't want to limit people to a set number of links and then deal with that, I want things to be generic enough that people can link to whatever they want. I ended up settling on this:

let Link = ./Link.dhall

in  { Type = { name : Text, tags : List Text, links : List Link.Type }
    , default =
      { name = "", tags = [] : List Text, links = [] : List Link.Type }
    }

This lets people link to whatever they want, such as like this:

-- dhall/signalboost/XeIaso.dhall
let xesite = ../types/package.dhall

let Link = xesite.Link

let Person = xesite.Person

in  Person::{
    , name = "Xe Iaso"
    , tags =
      [ "Go"
      , "Rust"
      , "Dhall"
      , "Nix"
      , "NixOS"
      ]
    , links =
      [ Link::{ url = "https://github.com/Xe", title = "GitHub" }
      , Link::{ url = "https://xeiaso.net", title = "Blog" }
      ]
    }

You can easily imagine how this would make things a lot simpler in practice. Instead of having to have specific fields for every kind of link someone could have, there's a list of links with a custom target and title. I hope this will make things simpler in practice.

I have also removed a lot of the older entries with people that I have determined to be employed. If I am mistaken, please submit a pull request with corrections.

Resume is now a PDF

I've hosted my resume on my blog for years. It's been a Markdown file (originally generated from a JSON document back when JSON resume was a thing) for the longest time. Whenever someone wanted a copy of my resume, I usually shoved that markdown file into Pandoc and gave them the resulting PDF. This has not scaled.

Recently I changed how my salary transpareny page works and in the process I put all of my job history information (including salaries) into a giant heckin' Dhall document. It was always my intention to come back around and use this data for the resume page, but I've been stuck on the exact best way to do this.

On Wednesday I had a bad idea. By the end of the day Thursday, I had it working. One of the features Dhall has is a string interpolation operator. If you write a document like this:

let bar = "bar"
in  "foo${bar}"

Dhall will return foobar. This means that you can use Dhall for both structured data and text templating. I've also been maintaining a separate immigration-friendly resume for a few years using Overleaf and LaTeX (turns out border agencies don't like it when you use a professional pseudonym on your resume, who knew). The bad idea was to shove the template into Dhall somehow so that Dhall would puke out LaTeX source code which would then be fed into a LaTeX compiler to turn into a PDF.

Of course, if I was going to do this, I couldn't just choose pdfTeX as my LaTeX compiler of choice. That's not on-brand enough. It just so turns out that there is an international-character friendly LaTeX compiler named XeTeX. I'm not kidding. It is so on-brand of me to use this that it hurts.

So I took all of the madness in my trollish heart and poured it into my emacs frame. I eventually ended up with resume.dhall. When you run dhall text on that file, you get all of that data transformed into LaTeX source code like this.

However having a bunch of LaTeX source code isn't useful by itself (unless you are also an immortal and can read LaTeX like I can). I wanted the resume to build itself so I cannot forget how this works. When thinking about build systems that are largely that ignorable, I usually turn to Nix. So I wrote a Nix package for building my resume and shoved it into the resulting package for my blog. It looks something like this:

# tex is texlive-medium plus a bunch of packages I need

resumePDF = pkgs.stdenv.mkDerivation {
  pname = "xesite-resume-pdf";
  inherit (bin) version;
  inherit src;
  buildInputs = with pkgs; [ dhall tex ];

  phases = "installPhase";

  installPhase = ''
    mkdir -p $out/static/resume
    cp -rf ${pkgs.dhallPackages.Prelude}/.cache .cache
    chmod -R u+w .cache
    export XDG_CACHE_HOME=.cache
    export DHALL_PRELUDE=${pkgs.dhallPackages.Prelude}/binary.dhall;

    ln -s $src/dhall/latex/resume.cls
    dhall text --file $src/dhall/latex/resume.dhall > resume.tex

    xelatex ./resume.tex
    cp resume.pdf $out/static/resume/resume.pdf
  '';
};

Now if I want to build my resume by itself, I can run this command:

$ nix build .#resumePDF

This should make it a lot easier to deal with recruiters!

I rewrote basically all of the templates with Maud

When I ported my website from Go to Rust back in 2020 I needed a library like Go's html/template to template out the HTML that my site uses. At the time there were many options I could pick from, but I ended up choosing ructe because it would compile the templates into my application binary instead of having to ship those with my website. This also means that the optimizer can chew through my templates and make them even faster than html/template. Native code will always be faster than interpreted code.

This worked for a while, but I started running into ergonomics problems as I continued to use ructe. The great part about ructe is that because the templates are compiled to Rust anyways, you can use any Rust logic or types you want. The horrible part about ructe is that your editor autocomplete and type checking logic doesn't work. Debugging compile failures of your templates requires that you understand how the generated code works. This isn't really as much of an issue as I'm making it sound like, but it's a papercut nonetheless.

A while ago I found the Rust library Maud. It's a procedural macro that uses a Rust-like syntax to emit HTML. It kinda looks like HTML if you squint. Compare these two identical documents:

<p>Hi there this is a test!</p>
html! {
  p { "Hi there this is a test!" }
}

It also lets you use splices to add the value of variables to templates and standard control structures to handle Option values or whatever.

I've wanted to move my site over to use them generically (and I've actually done most of the work to use them already for a lot of the shortcodes like the conversation snippets), so I took the time to do that. One of the easy to notice differences is the HTML of any page on the site. Before there was a lot of newlines and how everything is crammed into as few lines as possible.

Shockingly, doing all of these changes seems to have had no noticeable difference in how browsers render my website. I'm surprised too.

As of right now the only things left using ructe are my RSS/Atom feeds and the first implementation of conversation snippets. I am honestly afraid to change that last one, so I'm leaving it as-is because it works and I don't want to touch it.

Maybe this will make things load faster? I don't know. I'm not an HTML-ologist.

Pictures on the Patrons page

My patrons page has traditionally had a list of names. I thought I'd take advantage of rewriting the templates to make it a bit nicer looking, so I grabbed the avatar field out of everyone's entries and told my HTML template to put it in a fancy grid. This probably doesn't look nice on phones, but it looks great on my desktop and iPad so it's probably good enough.

Everything builds using flakes

I've maintained two builds of my site for a while. The Nix flakes one that I use in testing and the legacy Nix build that I use because I still haven't converted all of my projects on the server that runs this website to use flakes yet.

My site uses flake-compat to build the flakes build with a non-flakes environment. This is intended to make things easier, but I will still have CI build both the flakes and non-flakes build just in case.

Xesite finally uses Xeact properly

I've tried to use Xeact a few times on my blog. Nearly all of those attempts have been failures. I think this time will be different. I've had a share on Mastodon button on the bottom of every page for a few years. The old button used to use the browser prompt() function to query for your Mastodon instance and then it would pop a new tab to a precomposed toot that would mention me (so I can track usage of it).

More people use this than you'd think. Even more since all of the everything with Twitter started to happen. While I was rejiggering all of the backend stuff with templates, I thought I'd mix in Xeact more properly and use Xeact's JSX support to automagically compile things.

I ended up with the "Share on Mastodon" dropdown you'll see at the footer of this article. It's implemented using this TypeScript file. I'm happy with this so far, it does everything the old one did but just a bit better. It does use some invisible HTML elements to pass variables from the HTML template to the Xeact component, which I would love to change to JSON in a <script> tag or something, but this works for now.


Anyways, that's what I've been up to with Xesite! Thank you all for reading this, I never thought I'd get to the point where I've been working on the same project for almost 8 years. I usually pick up and abandon projects really quickly, so it's very odd that I have a bigger one that sticks around like this.

I'm super thankful for all of you reading and promoting this blog around. I've been using this blog to hone my writing talents and it's been really encouraging to see things hit the way I've wanted them to.

You know, I wonder how many articles I've written:

$ ls ./blog ./talks | wc -l
324

Holy crap. I write a lot. Given that my first commit was on January 31, 2015, that means that I've had this blog up for about 2855 days. Given I have 324 posts, this means that on average I have written an article about once every 9 days. This is kind of astounding.

$ nix run nixpkgs#lua5_3
Lua 5.3.6  Copyright (C) 1994-2020 Lua.org, PUC-Rio
> 2855/324
8.8117283950617

Here's to many more posts! Let's see if we can get that number down!
